| Model | CSS8004 |
|---|
| Drivers | 100 mm (4 in) |
|---|
| Sensitivity | 90 dB (2k - 6k Hz) |
|---|
| Frequency Range (-10 dB) Driver/Grille Assembly | 85 Hz – 18 kHz |
|---|
| Installed in CSS-BB backcan | 130 Hz – 18 kHz |
|---|
| Coverage Angle | 175° conical |
|---|
| Driver Continuous Power Handling | 15 Watts |
|---|
| Transformer Taps | 100V Taps - 5W, 2.5W, 1.3W 70V Taps - 5W, 2.5W, 1.3W, 0.7W 25V Taps - 5W, 2.5W, 1.3W, 0.7W |
|---|
| Transformer Insertion Loss | 1.5 dB Maximum |
|---|
| Transformer Connection | Bare wire |
|---|
| Motor Mass | 200 g (7 oz) |
|---|
| Safety Agency | Suitable for use in air handling spaces per UL1480, UL2043, NFPA 90 & NFPA 70, when installed with corresponding UL Listed backcan, below. S7232/UL Listed, Signaling Speaker. Transformer UL registered per UL1876. In accordance with IEC60849/EN60849. |
|---|
| Matching CSS Backcan | CSS-BB4 |
|---|
| Other Compatible Backcans | N/A |
|---|
| Bolt Mounting Circle to Backcan | 4 points on 165 mm(6.5 in) diameter |
|---|
| Cutout DiameterOpen-back | 125 mm (5.0 in) |
|---|
| In CSS-BB backcan | 170 mm (6.7 in) |
|---|
| Depth (behind grille) | 94 mm (3.7 in) |
|---|
| Grille Diameter | 198 mm (7.8 in) |
|---|
| Net Weight (each) | 0.90 kg (1.0 lb) |
|---|
