Features

200 mm (8 in) woofer with SBR surround

Integrated enclosure with large, tapered dual ports for warm, smooth bass response

Built-in passive crossover network enabling it to be used as part of a subwoofer-satellite system

Built-in 70V/100V multi-tap transformer, plus 8-ohm direct input

Full-face, easily paintable magnetic grilles

Top and side exit cable entry options

Robust and adaptable dogears for wide range of ceiling thicknesses

IP33 rated

Attribute

Value

Model

Control 440CS/T

Frequency Range (-10 dB)

32Hz - 300Hz

Power Capacity

150 W (600 W Peak), Cont. Pink Noise (2 hrs.) 100 W (400 W Peak) Cont. Pink Noise Power (100 hrs.)

Sensitivity (1m/1W)

95dB in ceiling near corner (π/2 loading)

Coverage Angle

Maximum SPL (1m)

117 dB Cont. pink noise (123 dB peak, π/2 loading)

Nominal Impedance

8Ω

Transformer Taps

70 V: 80 W, 40 W, 20 W & 10 W 100 V: 80 W, 40 W, 20 W

Drivers

200 mm (8 in) treated paper cone with SBR surround and high-performance magnet

Ceiling Cutout Size

307 mm (12.1 in)

Dimensions

351mm (13.8 in) H x 342 mm (13.5 in) dia. 337mm (13.3 in) from bottom of ceiling tile to top of backcan

Safety Agency Rating

Suitable for use in air handling spaces per UL 2043, NFPA 90A & NFPA 70, CSA C22.2 no. 205 listed. Listing per UL 1480A Speakers for Commercial and Professional Use. UL registered Transformer.

Environmental

IP rating: IP33 per EN/IEC 60529. Operating temperature: 0° C to 45 °C.

Optional Accessories

JBL-MTC-440BG black (RAL9004) round grille JBL-MTC-440SG white (RAL9003) square grille JBL-MTC-419NC new construction bracket JBL-MTC-419MR mud-ring construction bracket JBL-MTC-48TRX4 tile rail for 4' x 4' ceiling tiles

Color

Stock grille is White (RAL9003), paintable

Net Weight (ea)

8.72 kg (19.22 lbs)

Shipping Weight (pair)

25.02 kg (55.16 lbs)
