Features

200 mm (8 in) woofer and 25mm (1 in) soft-dome tweeter

Integrated enclosure that is ideal for installation in most ceiling plenum spaces

Built-in 70V/100V multi-tap transformer, plus 8-ohm direct input

Full-face, easily paintable magnetic grilles

Top and side cable entry options

Robust and adaptable dogears for wide range of ceiling thicknesses

IP33 rated

Attribute

Value

Model

Control 418C/T

Frequency Range (-10 dB)

57Hz - 20kHz

Power Capacity

135W (540W Peak) Cont. Pink Noise (2 hrs) 90W (360W Peak) Cont. Pink Noise (100 hrs)

Sensitivity (1m/1W)

92dB

Coverage Angle

100° conical

Maximum SPL (1m)

113 dB continuous pink noise (119 dB peak)

Nominal Impedance

8Ω

Transformer Taps

70 V: 60 W, 30 W, 15 W & 7.5 W 100 V: 60 W, 30 W, 15 W

Drivers

LF: 200 mm (8 in) with paper cone, SBR surround HF: 25 mm (1 in) soft dome

Ceiling Cutout Size

282 mm (11.1 in)

Dimensions

283 mm (11.3 in) H x 315 mm (12.6 in) dia. 271 mm (10.8 in) from bottom of ceiling tile to top of backcan

Safety Agency Rating

Suitable for use in air handling spaces per UL 2043, NFPA 90A & NFPA 70, CSA C22.2 no. 205 listed. Listing per UL 1480A Speakers for Commercial and Professional Use. UL registered Transformer.

Environmental

IP rating: IP33 per EN/IEC 60529. Operating temperature: 0° C to 45 °C.

Optional Accessories

JBL-MTC-418BG black (RAL9004) round grille JBL-MTC-418SG white (RAL9003) square grille JBL-MTC-447NC new construction bracket JBL-MTC-447MR mud-ring construction bracket JBL-MTC-48TRX4 tile rail for 4' x 4' ceiling tiles

Color

Stock grille is White (RAL9003), paintable

Net Weight (ea)

5.8 kg (12.79 lbs)

Shipping Weight (pair)

17.72 kg (39.07 lbs)

SKU Numbers
