Features

100 mm (4 in) woofer and 20mm (0.75 in) soft-dome tweeter

Integrated enclosure that is ideal for installation in most ceiling plenum spaces

Built-in 70V/100V multi-tap transformer, plus 8-ohm direct input

Full-face, easily paintable magnetic grilles

Top and side cable entry options

Robust and adaptable dogears for wide range of ceiling thicknesses

IP33 rated

Attribute

Value

Model

Control 414C/T

Frequency Range (-10 dB)

65Hz - 20kHz

Power Capacity

45W (180W Peak) Cont. Pink Noise (2 hrs) 30W (120W Peak) Cont. Pink Noise (100 hrs)

Sensitivity (1m/1W)

86dB

Coverage Angle

130° conical

Maximum SPL (1m)

103 dB continuous pink noise (109 dB peak)

Nominal Impedance

8Ω

Transformer Taps

70 V: 25 W, 12.5 W, 6.3 W & 3.2 W 100 V: 25 W, 12.5 W, 6.3 W

Drivers

LF: 100 mm (4.0 in) with paper cone, SBR surround. HF: 20 mm (0.75 in) soft dome

Ceiling Cutout Size

168 mm (6.6 in)

Dimensions

186 mm (7.4 in) H x 203 mm (8.1 in) dia. 177 mm (7.1 in) from bottom of ceiling tile to top of backcan

Safety Agency Rating

Suitable for use in air handling spaces per UL 2043, NFPA 90A & NFPA 70, CSA C22.2 no. 205 listed. Listing per UL 1480A Speakers for Commercial and Professional Use. UL registered Transformer.

Environmental

IP rating: IP33 per EN/IEC 60529. Operating temperature: 0° C to 45 °C.

Optional Accessories

JBL-MTC-414BG black (RAL9004) round grille JBL-MTC-414SG white (RAL9003) square grille JBL-MTC-414WG white (RAL9003) weather grille JBL-MTC-424NC new construction bracket JBL-MTC-424MR mud-ring construction bracket JBL-MTC-48TRX4 tile rail for 4' x 4' ceiling tiles

Color

Stock grille is White (RAL9003), paintable

Net Weight (ea)

2.50 kg (5.51 lbs)

Shipping Weight (pair)

9.52 kg (20.99 lbs)
