Features

24-channel premium mixing console

16 mic inputs with 48 V phantom and HPF per channel

24 line inputs (16 mono + 4 stereo)

D-PRE discrete Class-A mic preamps

X-pressive EQ

Stereo Hybrid Channel with mid-sweep 3-band EQ

REV-X reverb (8 programs) and SPX multi-effects (16 programs), usable together

48 V phantom power and HPF per mic channel

6 AUX sends + 2 FX sends

4 GROUP buses + stereo bus

USB device playback and recording

1 matrix out and 1 mono out

Attribute

Value

Model

MGP24X A

Mixing channels

24 line inputs (16 mono + 4 stereo)

Mic inputs

16 (HPF 100 Hz, 12 dB/oct)

Phantom power

48 V per channel

On-board processors

FX1: REV-X (8 programs); FX2: SPX (16 programs)

Digital I/O

USB device

GROUP

4 GROUP buses + ST bus

AUX

6 AUX sends + 2 FX sends

MATRIX

1 matrix out

Line inputs

16 mono + 4 stereo, 16 channel inserts, 1 stereo return

Frequency response

+0.5 / −1.0 dB, 20 Hz–20 kHz, nominal output @ 1 kHz

Total harmonic distortion

0.02% (20 Hz–20 kHz @ +14 dBu)

Equivalent input noise

−128 dBu

Residual output noise

−92 dBu

Power requirements

100–240 V, 50/60 Hz

Power consumption

86 W max

Dimensions (W × H × D)

819 × 169 × 565 mm (32.2 × 6.7 × 22.2 in)

Net weight

15.5 kg (34.2 lb)
