| Model | IP-A1PG |
|---|
| Power Source | PoE(IEEE802.3af Class 3) |
|---|
| Power Consumption | 2.5 W |
|---|
| Audio Codec | Opus, PCMU (G.711u), PCMA (G.711a), G.722 |
|---|
| Audio Delay Time | Min. 100 ms(*1) |
|---|
| Audio Transmission Method | Multicast Audio Streaming |
|---|
| Network I/F | 100BASE-TX, Auto MDI/MDI-X, RJ45 connector |
|---|
| Network Protocol | IP, TCP, UDP, TLS, HTTP, HTTPS, RTP, SRTP, RTSP, RTCP, SRTCP, ARP, ICMP, IGMPv3, NTP, SIP (RFC3261), SIPS, SIP-TLS, DHCP |
|---|
| Audio Input | 1 channel, electronically-balanced, 10 kΩ LINE/MIC selectable (Rated input: LINE: 0 dB (*2), MIC: -60 dB (*2) PAD function (-20 dB (*2), Phantom power ON/OFF (12 V DC), volume adjustable removable terminal block (6 pins) |
|---|
| Control Input | 4 channels, no-voltage make contact inputs, open voltage: 5 V DC, short-circuit current: 2 mA or less, removable terminal block (6 pins) |
|---|
| Control Output | 1 channel, open collector output, withstand voltage: 30 V DC, control current: 150 mA or less, removable terminal block (6 pins) |
|---|
| Mute Control Input | 1 channel, 24 V DC cut-off signal, control current 5 mA or less, non-polar, removable terminal block (2 pins) |
|---|
| Monitor Output | 1 channel, unbalanced, 600 Ω or less Rated output: 0 dB (*2), RCA pin jack |
|---|
| Indicator | STATUS (green/blue/orange/red), LINE/MIC IN (green/red), OUTPUT (green),LINK/ACT (green) |
|---|
| Clock Accuracy | ±13 seconds per month |
|---|
| Time Adjustment | Manual time setting, Time adjustment by NTP server |
|---|
| Power Outage Protection Period |
|---|
