18 attributes
| Attribute | Value |
|---|---|
| Model | IP-A1MP |
| Phantom Power | 9 V DC - 26 V DC |
| Current Consumption | 8 mA or less (at 12 V DC) |
| Microphone | Omni-directional electret condenser microphone |
| Frequency Response | 100 Hz - 10 kHz |
| Microphone Output | 0 dB (*1), 200 Ω, (Volume adjustable), electronically-balanced, push-in terminal block |
| Control Input | No-Voltage make contact input, open Voltage: 5 V DC, short-circuit current: 0.2 mA or less, push-in terminal block |
| Control Output | No-Voltage make contact output, withstand Voltage: 30 V DC, control current: 100 mA, push-in terminal block |
| Call Button | Momentary type (Control output circuit is closed while pressed) |
| Indicator | Green (Lit during control input) (*2) |
| Cable Requirements | Microphone output: Two-core shielded cable or Shielded twisted pair cable Control input/output: Twisted pair cable |
| Operating Temperature | -20 °C to +55 °C (-4 °F to 131 °F) |
| Operating Humidity | 90 %RH or less (no condensation) |
| Finish | Front case: Surface-treated steel plate, white (RAL 9016 equivalent), semi-gloss, paint Rear case, bracket: Surface-treated steel plate, black zinc plating Plate: ABS resin, white (RAL 9016 equivalent), gloss |
| Dimensions | 44.6 (W) x 107 (H) x 29 (D) mm (1.76" x 4.21" x 1.14") (excluding projection) |
| Weight | 170 g (0.37 lb) |
| Included Accessories | Plate x 1, Plate mounting screw (M3.5 x 5.5, preinstalled on the plate) x 2, Box mounting screw (M4 x 35) x 2 |
| Compatible Box | Flush-Mount Box: YC-801 Wall-Mount Box: YC-802 |
|---|
