Soundcraft Ui16 Digital Mixers

16-channel digital mixer with built-in Wi-Fi, HARMAN processing, and browser-based remote control.

Brand: SoundcraftModel: Ui16

The Ui Series mixers feature cross-platform compatibility with iOS, Android, Windows, Mac OS, and Linux devices, and can use up to 10 control devices simultaneously. In addition, the Ui12 and Ui16 each feature built-in HARMAN signal processing from dbx, DigiTech and Lexicon, including dbx AFS2, DigiTech Amp Modeling, and more. Both models feature fully recallable and remote-controlled mic gain and phantom power, along with 4-band parametric EQ, high-pass filter, compressor, de-esser and noise gate on input channels. The Ui16 boasts eight XLR combo mic/line inputs, four XLR mic inputs, two channels of Hi-Z/instrument inputs, as well as a stereo RCA line input. A 2-channel USB media player is included, along with four balanced XLR Aux outputs, two quarter-inch headphone outputs with level control, plus balanced stereo XLR and quarter-inch main outputs.

Features

Tablet/PC/Smartphone controlled digital mixer with integrated Wi-Fi

Cross-platform control: iOS, Android, Windows, Mac OS, and Linux

Up to 10 control devices simultaneously

HARMAN processing from dbx, DigiTech, and Lexicon

Fully recallable remote-controlled mic preamps and phantom power

4-band parametric EQ, HPF, compressor, de-esser and noise gate on inputs

31-band graphic EQ, noise gate and compressor on all outputs

Real-time frequency analyser (RTA) on inputs and outputs

3 dedicated Lexicon FX processors: Reverb, Delay and Chorus

2-channel USB audio playback and recording

Attribute

Value

Model

Ui16

Channels

Height

110 mm (4.3")

Width

177 mm (7.0")

Length

483 mm (19.0")

Weight

3.61 kg (7.9 lb)

Mic/line inputs

8 XLR combo

Mic inputs

4 XLR

Hi-Z inputs

Line input

Stereo RCA

Aux outputs

4 balanced XLR

Main outputs

Balanced stereo XLR and 1/4"

USB playback/record

2-channel

Control

Built-in Wi-Fi and Ethernet
