Soundcraft Ui12 Digital Mixers

12-channel digital mixer with built-in Wi-Fi, HARMAN processing, and browser-based remote control.

Brand: SoundcraftModel: Ui12

The Ui Series mixers feature cross-platform compatibility with iOS, Android, Windows, Mac OS, and Linux devices, and can use up to 10 control devices simultaneously. In addition, the Ui12 and Ui16 each feature built-in HARMAN signal processing from dbx, DigiTech and Lexicon, including dbx AFS2, DigiTech Amp Modeling, and more. Both models feature fully recallable and remote-controlled mic gain and phantom power, along with 4-band parametric EQ, high-pass filter, compressor, de-esser and noise gate on input channels. The Ui12 also features four XLR combo mic/line inputs, four XLR mic inputs, two channels of Hi-Z/instrument inputs, as well as a stereo RCA line input. A 2-channel USB media player is included, along with two balanced XLR Aux outputs, two quarter-inch headphone outputs with level control, plus balanced stereo XLR and quarter-inch main outputs.

Features

Tablet/PC/Smartphone controlled digital mixer with integrated Wi-Fi

Cross-platform control: iOS, Android, Windows, Mac OS, and Linux

Up to 10 control devices simultaneously

HARMAN processing from dbx, DigiTech, and Lexicon

Fully recallable remote-controlled mic preamps

4-band parametric EQ, HPF, compressor, de-esser and noise gate on inputs

31-band graphic EQ, noise gate and compressor on all outputs

Real-time frequency analyser (RTA) on inputs and outputs

3 dedicated Lexicon FX processors: Reverb, Delay and Chorus

Show/Snapshot recall with channel safes and security lockout

Attribute

Value

Model

Ui12

Channels

Height

85 mm (3.3")

Width

177 mm (7.0")

Length

320 mm (12.6")

Weight

2.29 kg (5.0 lb)

Mic/line inputs

4 XLR combo

Mic inputs

4 XLR

Hi-Z inputs

Line input

Stereo RCA

Aux outputs

2 balanced XLR

Main outputs

Balanced stereo XLR and 1/4"

USB playback

2-channel

Control

Built-in Wi-Fi and Ethernet
