View larger image of JBL VTX V25-II — official product photo
14 attributes
| Attribute | Value |
|---|---|
| Model | VTX V25-II |
| System Type | Full Size 3-Way High Directivity Line Array Element with D2 Dual Drivers |
| Frequency Range (-10dB) | 35Hz - 18 kHz (Preset: VTX V25-II) |
| Horizontal Coverage (-6 dB) | 90 degrees nominal (200 Hz - 16 kHz) |
| Maximum Peak Output | LF: 141 dB MF: 140.5 dB HF: 149.5 dB |
| System Amplification | Crown Audio I-Tech HD |
| Nominal Impedance | LF: 2x 8 ohms MF: 8 ohms HF: 8 ohms |
| LF Driver | (2) JBL 2267H 15-inch woofer |
| MF Driver | (4) JBL 2168H 8-inch mid-frequency driver |
| HF Driver | (3) JBL 2430K D2 Dual Diaphragm Dual Voice Coil Compression Driver |
| Enclosure | Cast aluminum front baffle, Finnish birch plywood, black DuraFlex finish; four integral recessed handles |
| Inter-enclosure Angle | 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10 |
| Dimensions (H x W x D) | 414 mm x 1223 mm x 614 mm 16.3 in x 48.2 in x 24.2 in |
| Net Weight (each) | 82.6 kg (182 lb) |
