Features

Constant Curvature Array - The waveguide mounts two compression drivers on a continuous arc enabling them to work together acoustically as if they were a single driver.

Amplitude Shading- Convenient series of switches on each enclosures that controls the output of each high frequency section in the array.

Suspension and Rigging.

Dual Angle Pole Socket - JBL's dual angle pole sockets allow great flexibility in aiming the enclosure (not on - WH version)

Differential Drive Woofer.

Attribute

Value

Model

VRX928LA

Power Rating

400 W / 800 W / 1600W

Frequency Range (-10dB)

70 Hz - 20 kHz

Dimensions (H x W x D)

230mm x 420mm x 270mm (9.0in x 16.5in x 10.5in)

Coverage Pattern

100 x 15 nominal

Frequency Response (±3 dB)

85 Hz - 19 Hz

Crossover Modes

Bi-amp / passive,

Crossover Frequency

2.0 kHz

Net Weight (each)

12.7 kg (28 lb)

Inputs

Neutrik Speakon NL-4 (x2)

Outputs

1 x XLR

Enclosure

Duraflex coated plywood

System Type

Constant Curvature 8" Two-Way Line Array System

Maximum SPL (1m)

122 dB SPL peak (passive mode) LF: 122 dB (bi-amp mode) HF: 128 dB (bi-amp mode)

Nominal Impedance

Passive = 8 ohm Bi-amp LF = 8 ohm Bi-amp HF = 16 ohm

LF Driver

1 x 200 mm (8 in) Differential Drive woofer

HF Driver

2 x 25 mm (1.0 in) neodymium compression driver

Suspension / Mounting

Dual 36 mm pole socket included. Suspension requires optional VRX-SMAF line array frame kit or M10 eyebolts.
