View larger image of JBL SRX835P — official product photo
19 attributes
| Attribute | Value |
|---|---|
| Model | SRX835P |
| System Type | Self powered 15”, three-way, bass-reflex |
| Maximum SPL (1m) | 137 dB |
| Frequency Range (-10dB) | 33 Hz - 21 kHz |
| Frequency Response (±3 dB) | 41 Hz - 20 kHz |
| Coverage Pattern | 60° x 40° |
| Amplifier Design | Class D |
| Power Rating | 2000 W Peak |
| Dimensions (H x W x D) | 476mm x 544mm x 984mm (18.74in x 21.4in x 38.74in) |
| Net Weight (each) | 38.6 kg (85 lb) |
| EQ | 20 parametric EQ's, speaker delay, and 50 available slots for presets |
| Inputs | Neutrik ¼ - XLR input; Neutrik XLR Output |
| Outputs | 2 x XLR |
| Enclosure | 18 mm, 11-ply Finnish birch plywood; black DuraFlex finish; integral recessed handles |
| Nominal Impedance | NA - amplification is integrated |
| LF Driver | 1 x 2275F, Differential Drive, 15" diameter |
| MF Driver | 1 x 2107H |
| HF Driver | 1 x 2432H compression driver, neodymium 76mm (3 in) diameter voice coil |
| Suspension / Mounting | Single 36 mm pole socket, 12 x M10 suspension points |
