Features

1000-watt peak Class-D power

8-inch woofer and 1.4-inch HF compression driver

124 dB peak SPL at 1 m

90° DMT™ axisymmetric coverage

Intrinsic Correction™ loudspeaker processing

One-touch contours: Default, Dance, Floor Monitor, Speech

3-channel mixer with XLR mix output

Ultra-compact 9.5 kg (21 lb) polypropylene enclosure

55° monitor wedge, 35 mm pole socket, and M8 insert

6-Year Warranty when registered within 30 days of purchase

Attribute

Value

Model

CP8

Configuration

Two-way active loudspeaker

LF transducer

203 mm (8 in) cone

HF transducer

35.6 mm (1.4 in) compression driver

Frequency response (−6 dB)

56 Hz–20 kHz

Frequency range (−10 dB)

53 Hz–20 kHz

Coverage

90° axisymmetric

Maximum SPL

124 dB peak

Amplifier

Class D, peak 800 W LF + 200 W HF

Connectors

2 × locking XLR/F 1/4" combo, 1 × 3.5 mm TRS, 1 × XLR/M mix out, IEC

AC power

100–240 VAC, 50–60 Hz

Enclosure

Polypropylene

Color

Black (RAL 9011)

Dimensions

411 × 273 × 256 mm (H × W × D)

Net weight

9.5 kg / 21.0 lb
