Features

Best in class audio performance

2000 Watt Class-D amplifier module

Intrinsic Correction™ tuning and loudspeaker management

Directivity Matched Transition® (DMT) design for consistent coverage

Rugged ABS enclosure with a professional appearance

Main PA or floor monitor deployment

Factory presets and savable/recallable scenes

Multi-function LCD for crossover, EQ, delay, and contour

Dual pole cups (straight and 7.5° down-tilt)

M10 fittings for flown applications

6-Year Warranty when registered within 30 days of purchase

Attribute

Value

Model

K12.2

Configuration

Multi-purpose 2-way active loudspeaker

LF transducer

305 mm (12-inch) cone

HF transducer

35.6 mm (1.4-inch) titanium diaphragm compression driver

Frequency response (−6 dB)

50 Hz–20 kHz

Frequency range (−10 dB)

45 Hz–20 kHz

Coverage

75° axisymmetric

Maximum SPL

132 dB peak / 126 dB continuous

Amplifier

Class D, peak 1800 W LF + 225 W HF

Connectors

2 × locking XLR/F 1/4" combo, 3.5 mm TRS, 2 × XLR/M loop-thru, mix out, IEC

AC power

100–240 VAC, 50–60 Hz

Enclosure

Impact-resistant ABS

Color

Black (RAL 9011)

Dimensions

602 × 356 × 350 mm (H × W × D)

Net weight

17.7 kg / 39 lb
