| Model | EON712 |
|---|
| System Type | 12IN Powered Loudspeaker |
|---|
| Woofer Model | 712G |
|---|
| Woofer Size | 12" |
|---|
| Woofer Magnet | Ferrite |
|---|
| Woofer Voice Coil | 2" |
|---|
| Tweeter Model | 2414H Compression Driver |
|---|
| Tweeter Size | 1'' |
|---|
| Tweeter Magnet | Neodymium |
|---|
| Transducer Impedence | LF 4ohm rated, HF 8ohm rated |
|---|
| Max SPL | 127dB @1m/4Pi |
|---|
| Freq Range -10 | 50Hz - 20kHz |
|---|
| Freq Range -3 | 60Hz - 20kHz |
|---|
| Hor Dispersion | 100° |
|---|
| Vert Dispersion | 60° |
|---|
| Power Rating | 1300W peak / 650 RMS |
|---|
| AC power input | 100V-120V or 220V-240V |
|---|
| Cooling | Passive |
|---|
| LED indicators | 1 Power LED, 1 Limit LED, 1 Front LED, 2 Signal/SSM LEDs |
|---|
| Input Impedance | 50k/100k un-balanced/balanced |
|---|
| Input Gain | -∞to +36db |
|---|
| Crossover Frequency | 2 kHz |
|---|
| I/O | 2 XLR Combo Jacks / BT 1 XLR M Thru |
|---|
| Cabinet | PP+10% Talc |
|---|
| Grille | 16GA perforated steel with acoustically transparent black cloth backing |
|---|
|
