View larger image of Electro-Voice ZLX-15P G2 — official front three-quarter view
34 attributes
| Attribute | Value |
|---|---|
| Brand | Electro-Voice |
| Series | ZLX G2 |
| Model | ZLX-15P G2 |
| Material Number | Z.01X.000.110 |
| Configuration | 2-way |
| Max SPL | 129 dB |
| Frequency response low (-3 dB) (Hz) | 48 Hz |
| Frequency response high (-3 dB) (Hz) | 18000 Hz |
| Frequency Range (-10 dB) | 42 Hz - 20 kHz |
| Coverage angle (H) | 90 ° |
| Coverage Angle | 90 × 60 |
| LF transducer size (in) | 15 |
| HF transducer size (in) | 1.4 |
| LF transducer size (mm) | 381 |
| HF transducer size (mm) | 36 |
| Total Output Power* | 1000 |
| Operating Voltage / Power | 100-240 V, 50/60 Hz |
| DSP | Yes |
| DSP Presets | Live; Music; Speech; Club; + EV subwoofer presets |
| Connectivity | 2 x XLR/TRS combo; Bluetooth |
| Color | Black |
| Enclosure | Polypropylene |
| Grille | Powder-coated steel |
| Mounting Type | Pole-mount; Stand-mount; M8 rigging points |
| Net weight |
| 16780 |
| Dimension depth (in) | 15.08 in |
|---|
| Dimension depth (mm) | 383.1 |
|---|
| Dimension height (in) | 27.46 in |
|---|
| Dimension height (mm) | 697.6 |
|---|
| Dimension width (in) | 16.65 in |
|---|
| Dimension width (mm) | 422.8 |
|---|
| Dimensions (H x W x D) (in) | 27.46 x 16.65 x 15.08 |
|---|
| Dimensions (H x W x D) (mm) | 697.6 x 422.8 x 383.1 |
|---|
| Series / Family | ZLX G2 |
|---|
