View larger image of Electro-Voice EVIVA 12P — official front three-quarter view
23 attributes
| Attribute | Value |
|---|---|
| Brand | Electro-Voice |
| Series | EVIVA |
| Model | EVIVA 12P |
| Material Number | F.01U.426.606 |
| Max SPL | 125 dB |
| Frequency response low (-3 dB) (Hz) | 63 Hz |
| Frequency response high (-3 dB) (Hz) | 18000 Hz |
| Frequency Response | 63 Hz – 18,000 Hz |
| Frequency Range (-10 dB) | 50 Hz – 20,000 Hz |
| Coverage Angle | 90 × 60 |
| LF transducer size (in) | 12 |
| HF transducer size (in) | 1 |
| Amplifier Watt Peak | 1000 W |
| Power consumption (W) | 100 - 240 V~, 50 - 60 Hz, 1.0 - 0.5 A |
| Connectivity | (2) XLR Combo mic/line input (1) XLR mix output |
| Color | Black |
| Enclosure | Composite |
| Grille | Powder coated steel |
| Net weight | 12.0 kg |
| Shipping Weight | 15.5 kg |
| Dimensions (H x W x D) (in) | 23.74 in x 13.89 in x 13.86 in |
| Dimensions (H x W x D) (mm) | 603 mm x 353 mm x 352 mm |
| Series / Family | EVIVA |
