Val Audio X15CXA Active Speakers

The VAL Audio X15CXA is a next-generation powered coaxial stage monitor designed to meet the demands of today’s professional performers and sound engineers. At its core is a precis

Brand: Val AudioModel: X15CXA

The VAL Audio X15CXA is a next-generation powered coaxial stage monitor designed to meet the demands of today’s professional performers and sound engineers. At its core is a precision-engineered coaxial transducer system, where a 15” low-frequency driver and a 2” high-frequency compression driver share a common axis. This alignment ensures phase-accurate sound reproduction, seamless frequency integration, and consistent coverage across the entire listening area — a critical advantage for stage monitoring where clarity and uniformity are paramount. Driven by a high-efficiency Class-D amplifier delivering 1200W Peak / 600W RMS, the X15CXA combines raw power with refined control. The integrated DSP offers four presets, EQ-high/mid/low control, delay, and high-pass filtering, allowing the monitor to be adapted instantly for vocals, instruments, or full-range stage mixes. A built-in two-channel mixer with mic/line inputs, AUX and XLR output further enhances flexibility, making the X15CXA equally at home in touring rigs, corporate events or fixed installations. Designed with both performance and practicality in mind, the X15CA features a low-profile wedge enclosure that keeps sightlines clear while ensuring optimal monitoring angles. Multiple handles, a rugged protective grille, and a pole-mount option add versatility and durability, making it a reliable workhorse for the most demanding live sound environments.

Features

Coaxial Speaker Design – 15” woofer with 2” HF compression driver in coaxial alignment for natural, phase-accurate sound High-Powered

Amplification – Class-D bi-amplified system delivering 1200W Peak / 600W RMS power output Integrated DSP

– Multi-function DSP with 4 presets, EQ, delay, and high-pass filter

Flexible Connectivity – Two-channel mixer with mic/line input, ¼” combo jack, 3.5mm AUX and XLR mix output

Optimized Frequency Response – Wide, balanced coverage ensuring clarity on any stage

Portable & Versatile – Low-profile wedge design with pole-mount option and multiple carry handles

Durable Construction – Rugged cabinet, protective grille, and professional-grade components for touring reliability

Attribute

Value

Model

X15CXA

Components

1×15” woofer, 2” HF compression driver

System Type

Powered Coaxial Stage Monitor

Frequency Response

45Hz – 20kHz

Maximum SPL

133dB

Sensitivity

99dB

Coverage (H x V)

90° x 90°

Power Amplifier

Class D, Bi-amp 1200W Peak / 600W RMS power output

Integrated DSP

Master level control Fixed 4 Presets EQ – High,Mid,Low Delay High-pass

LCD Display

Integrated with brightness control

Low Frequency Driver

1 x 15’’ (3” VC)

High Frequency Driver

2” compression driver (coaxially mounted)

Connectors

2 x XLR/TRS combo Mic/Line Inputs 1 x 3.5mm stereo Input 1 x XLR Mix Out

AC Power Input

PowerCON Input and Thru – 230VAC, 50Hz

Power Consumption

Idle: 20W, Full Power: 340W

Enclosure

Low-profile wedge, pole-mount capable, high quality wooden cabinet

Carry Handles

Yes

Monitor Wedge

Yes

Grille

Steel grille with acoustic foam

Finish

Polyurea paint

Colour

Black

Dimensions (HxWxD)

390 x 535 x 490 mm

Net Weight

22.65 Kg
