Val Audio WCX15L-500 Passive Line Array Loudspeakers

The VAL audio WCX15L-500 is an advanced 15″ two-way coaxial line array speaker, meticulously engineered for all-weather reliability and superior audio performance. Its cabinet is c

Brand: Val AudioModel: WCX15L-500

The VAL audio WCX15L-500 is an advanced 15″ two-way coaxial line array speaker, meticulously engineered for all-weather reliability and superior audio performance. Its cabinet is constructed from a specialized polymer compound through injection moulding, providing exceptional resistance to UV radiation, dust, and wind. The speaker is equipped with custom-designed dustproof and waterproof covers for both input and output connections, along with a sophisticated five-layer grille that ensures effective prevention of water and dust ingress. It meets the rigorous IP56 standard for weatherproofing. Exposed metal components are crafted from high-grade stainless steel or aluminium, chosen for their durability and resistance to corrosion, while the mounting bracket is treated with a low-carbon steel coating to ensure resilience against the elements. The WCX15L-500 features a powerful 15″ ferrite mid-bass driver and a coaxially mounted 3″ voice coil high-frequency driver, integrated into a precisely engineered 60° x 25° waveguide for optimal sound dispersion and clarity. Its versatile design allows the WCX15L-500 to be utilized as a standalone speaker or in arrays of up to four units, with the option of additional flying hardware for flexible installation configurations. This adaptability makes it suitable for a wide range of large-scale audio applications, from outdoor events to permanent installations.

Attribute

Value

Model

WCX15L-500

Components

1×15” LF, 1×1.4” exit coaxial HF

Power Handling

500W RMS / 1000W Program /2000W Peak

Impedance

8 ohm

Max SPL

136 dB

Nominal Impedance

8 ohms

Frequency Response (-10dB)

45Hz – 20KHz

Average Sensitivity

103dB (1W/1M)

Maximum SPL

130dB continuous / 133dB Program / 136dB peak

Low Frequency driver

1 x 15’’ (3’’ voice coil) ferrite woofer

High Frequency driver

1 x 1.4’’ (3’’ voice coil) driver coaxially mounted on waveguide

Crossover Frequency

1.5kHz passive

Dispersion (-6dB)

60° x 25°

Input Connectors

Covered barrier strip terminals

Size (WxHxD)

499mm x 500mm x 598mm

Net Weight

29 Kg

Gross Weight

32 Kg
