Val Audio VLA212HP Passive Line Array Loudspeakers

The VAL VLA212HP is a powerful dual 12” 2-way passive line array loudspeaker, purpose-built to deliver uncompromising performance in the most demanding live sound applications. Des

Brand: Val AudioModel: VLA212HP

The VAL VLA212HP is a powerful dual 12” 2-way passive line array loudspeaker, purpose-built to deliver uncompromising performance in the most demanding live sound applications. Designed for both touring sound systems and fixed installations, the VLA212HP combines high output capability, precise coverage control, and pristine sound clarity in a compact yet rugged enclosure. At its core, the system features two high-power 12” LF drivers that provide exceptional low-mid energy and punch, seamlessly paired with a high-efficiency 3” neodymium HF compression driver mounted on a custom waveguide. This driver combination ensures extended frequency response, low distortion, and the ability to project clear, intelligible audio over long distances with uniform horizontal dispersion. With its integrated rigging system, the VLA212HP is engineered for ease of deployment, offering safe and quick setup for scalable vertical array configurations. Its robust birch plywood cabinet, finished with a durable textured coating and protected by a heavy-duty steel grille, makes it fully road-ready for rental and touring use while maintaining a refined aesthetic for installation projects.

Features

Dual 12” high-power LF drivers for extended low-mid punch and depth High-efficiency 3” neodymium HF compression driver with precision waveguide for articulate high-frequency projection 140dB peak SPL output, ensuring powerful performance for large-scale events 90° (H) x 10° (V) coverage pattern, optimized for line array deployment and consistent audience coverage

Integrated rigging hardware for quick, safe, and flexible array configurations Tour-grade construction with premium birch plywood enclosure and reinforced steel grille for maximum durability

Compact design delivering high output-to-size ratio, ideal for both portable and permanent setups

Attribute

Value

Model

VLA212HP

Components

2×12” LF, 1.5” exit HF

Power Handling

1200W RMS / 2400W Program / 4800W Peak

Impedance

4 ohm

Max SPL

140 dB

Type

2-way passive line array loudspeaker

Nominal Impedance

4Ω

Frequency Response (-10 dB)

45Hz – 20kHz

Average Sensitivity (1W/1m)

103dB

Maximum SPL

134dB continuous / 137dB program / 140dB peak

Coverage Pattern (H × V)

90° × 10°

LF Drivers

2 × 12” (3” VC) high-power ferrite drivers

HF Driver

1.5” exit, 1 × 3” (75mm) diaphragm, neodymium compression driver on waveguide

Crossover

Internal passive

Enclosure Material

Premium birch plywood, textured black finish

Connectors

2 × Speakon NL4 (1+1− input, 2+2− thru)

Rigging Hardware

Integrated rigging system

Dimensions (W × H × D)

875 × 360 × 528 mm

Net Weight

40 Kg
