Features

JBL 2285H 15-inch woofer offers low distortion and improved linearity

SlipStream double-flared ports reduce noise and air turbulence

Differential Drive dual-voicecoil, dual-gap woofer design delivers superior low-frequency performance in a compact footprint

Two B15 models are available – the B15G and the B15. The B15G is acoustically identical to the B15 but designed without rigging hardware, reducing weight and cost for situations where rigging is not required

Integrates seamlessly with JBL LAC-3, Array Link and Performance Manager software applications

Support for omnidirectional and cardioid array configurations

Available accessories include ground stack accessory and transportation accessories

Neutrik STX speakON NL4 connectors

Rugged, exterior-grade birch plywood enclosure with black Duraflex finish and recessed handholds

Powder-coated, hex-perforated stainless steel grille with acoustically transparent cloth backing

Attribute

Value

Model

VTX B15G

Frequency Range (-10dB)

35 Hz-95 Hz (Preset: 80 Hz)

Coverage Pattern

Omnidirectional or Cardioid

Maximum SPL (1m)

132 dB (Preset: 80 Hz)

System Processing

Crown iTech 9000HD, Crown iTech 12000HD Crown iTech 4x3500HD

Nominal Impedance

8 ohms

LF Driver

(1) JBL 2285H, 15 in diameter, dual 4 in diameter voice coil, neodymium Differential Drive

Enclosure

15 mm, 18 mm and 24 mm exterior grade birch plywood, black DuraFlexTM finish, two integral recessed handles

Dimensions (H x W x D)

446 mm x 536 mm x 586 mm 18.3 in x 21.1 in x 23.1 in

Net Weight (each)

41.5 kg (91.5 lbs)
