Features

Premium JBL Transducers

Rugged, versatile enclosures

Tunings available for Crown amps and dbx signal processors

Fully supported in Audio Architect

Power Handling: 3200W Peak, 1600W Program, 800W Continuous

Frequency Range: 32Hz-20kHz

Frequency Response: 43Hz-20kHz

Max SPL: 130dB (Peak)

Coverage Pattern: 60x40

Amplification options: Passive/Bi-Amp

Live performance systems.

Mobile and fixed DJ systems.

Attribute

Value

Model

SRX835

System Type

Passive 15”, three-way, bass-reflex

Maximum SPL Output

124dB (Continuous), 130dB (Peak)

Frequency Range (-10dB)

32hz - 20khz

Frequency Response (-3 dB)

43Hz - 20Hz

Sensitivity

95dB

System Power Rating

3200W Peak, 1600W Program, 800W Continuous

Nominal Impedance

8 Ohm

Inputs

NL4 Input, NL4 Loop-thru (+/-1 or +/-2 Selectable)

Operational Modes

Passive/Bi-Amp

LF Driver

JBL 2275F

MF Driver

JBL 2107H

HF Driver

JBL 2432H

Coverage Pattern

60 x 40

Crossover Frequency

330hz & 2.4khz

Enclosure

18mm Duraflex coated plywood

Suspension/Mounting

Single 36mm pole socket, 12 x M10 Suspension points

Handles

Finish

Obsidian Duraflex finish

Grille

Powder coated, Obsidian, 14-gauge perforated steel with acoustically transparent black cloth backing

Dimensions (H x W x D)

476mm x 544mm x 984mm (18.74in x 21.4in x 38.74in)

Weight

95.0 lbs (43.1kg)
