View larger image of JBL SRX815 — official product photo
23 attributes
| Attribute | Value |
|---|---|
| Model | SRX815 |
| System Type | Passive 15”, two-way, bass-reflex |
| Maximum SPL Output | 124dB (Continuous), 130dB (Peak) |
| Frequency Range (-10dB) | 41hz - 20khz |
| Frequency Response (-3 dB) | 56hz - 20khz |
| Sensitivity | 95dB |
| System Power Rating | 3200W Peak, 1600W Program, 800W Continuous |
| Nominal Impedance | 8 Ohm |
| Inputs | NL4 Input, NL4 Loop-thru (+/-1 or +/-2 Selectable) |
| Operational Modes | Passive/Bi-Amp |
| LF Driver | JBL 2275H |
| HF Driver | JBL 2432H |
| Coverage Pattern | 90 x 50 |
| Crossover Frequency | 1.9khz |
| Enclosure | 18mm Duraflex coated plywood |
| Monitor Angle | 50° |
| Suspension/Mounting | Dual 36mm pole socket, 12 x M10 Suspension points |
| Handles | 3 |
| Finish | Obsidian Duraflex finish |
| Grille | Powder coated, Obsidian, 14-gauge perforated steel with acoustically transparent black cloth backing |
| Dimensions (H x W x D) | 478mm x 458mm x 691mm (18.82in x 18.03in x 27.20in |
| Weight | 57.0 lbs (25.9kg) |
| Shipping Weight | 67.0 lbs (30.4kg) |
