View larger image of JBL SRX812 — official product photo
23 attributes
| Attribute | Value |
|---|---|
| Model | SRX812 |
| System Type | Passive 12”, two-way, bass-reflex |
| Maximum SPL Output | 123dB (Continuous), 129dB (Peak) |
| Frequency Range (-10dB) | 41hz - 20khz |
| Frequency Response (-3 dB) | 57hz - 20khz |
| Sensitivity | 94dB |
| System Power Rating | 3200W Peak, 1600W Program, 800W Continuous |
| Nominal Impedance | 8 Ohm |
| Inputs | NL4 Input, NL4 Loop-thru (+/-1 or +/-2 Selectable) |
| Operational Modes | Passive/Bi-Amp |
| LF Driver | JBL 2272H |
| HF Driver | JBL 2432H |
| Coverage Pattern | 90 x 50 |
| Crossover Frequency | 1.9khz |
| Enclosure | 18mm Duraflex coated plywood |
| Monitor Angle | 50° |
| Suspension/Mounting | Dual 36mm pole socket, 12 x M10 Suspension points |
| Handles | 3 |
| Finish | Obsidian Duraflex finish |
| Grille | Powder coated, Obsidian, 14-gauge perforated steel with acoustically transparent black cloth backing |
| Dimensions (H x W x D) | 429mm x 415mm x 638mm (16.87in x 16.31in x 25.11in) |
| Weight | 55.0 lbs (24.9kg) |
| Shipping Weight | 65 lbs (29.3kg) |
