Features

Components: 200 mm (8 in) polymer-coated aluminum-cone woofer with pure butyl rubber surround. 25 mm (1 in) pure-titanium dome low-diffraction swivel aimable titanium tweeter.

High-slope crossover for natural midrange sound.

Extended bandwidth performance of 30 Hz – 20 kHz.

60 W continuous (120 W program, 240 W peak) Power handling (128 W).

Attribute

Value

Model

Control 128 W

Frequency Range

30 Hz - 20 kHz (-10 dB)

Power Rating

200 W Peak 100 W Continuous Program Power 50W Continuous Pink Noise

Sensitivity

90 dB SPL

Coverage Angle

180°H x 160°V

Impedance

8 ohms

Drivers

LF: 200 mm (8 in) polymer-coated aluminum cone, pure butyl rubber surround. HF: 25 mm (1 in) pure-titanium dome with cloth suspension on low-diffraction swivel-mount with -10 degree aimability.

Input Connectors

Screw-down Euroblock-type connector. Max wire size 14 AWG (1.5 mm)2

Crossover Network

2nd order Low Pass to the woofer and 2nd order High Pass to the tweeter.

Optimum Air Cavity Behind Speaker

40 to 80 liters (1.4 to 2.8 cu ft)

Outside Dimensions (H x W x D)

334 x 257 x 110 mm (13.1 x 10.1 x 4.3 in), 102 mm (4.0 in) front of wall to back of speaker.

Maximum Wall Thickness

32 mm (1.25 in)

Cutout Size (H x W)

300 x 225 mm (11.9 x 8.9 in), Cutout template included.
