JBL 9350 Cinema Surrounds

High Output/High Impact Cinema Surround Loudspeaker w/Configurable Pattern

Brand: JBL ProfessionalModel: 9350

The 9350 packs a sonic punch, and delivers extraordinary coverage through its advanced engineering, including three patent-pending technologies. Each loudspeaker generates a sculpted side or rear pattern, adjusted with the flick of a switch. With a passive crossover network, waveguide technologies, and line array techniques, coverage can be adjusted to fit a theatre's unique environment. The 9350 further enhances coverage by configurable vertical and horizontal coverage angles based on whether the surround is located on the rear or side wall location. The result? Premium performance and left/right balance overall, an accomplishment unheard of in cinema. It means the sonic sweet spot just got a whole lot bigger, and that sculpted, impactful sound now comes from all sides. Ultimately, the audience becomes immersed in an audio experience like none other. Rely on the 9350, the ideal complement to front screen loudspeakers, for superior sonic character and dynamics - everywhere.

Request a quote WhatsApp

Compare with similar

Features

Creates line array pattern control with just two horns
Simple switch engages a sculpted side or rear coverage pattern
Extends HF output power and pattern control a full octave in both spectrum extremes
Greatly improves midrange performance of the Differential Drive 15" woofer
Smooth crossover transition created by very tight driver spacing and control of break up mode energy
Acoustic Divider waveguide creates a low frequency acoustic Bi-pole
Reduces wall reflection notching typical of surrounds by shaping rear hemisphere energy

Specifications

23 attributes

Attribute	Value
Model	9350
Frequency Range (±3 dB)	40 Hz - 18kHz
Frequency Range (-10dB)	34 Hz - 20kHz
Power Handling (2Hr AES Rating)	350W
Maximum SPL (1m)	130dB continuous, 133dB peak
Horizontal Coverage Angle (-6dB)	70° / 120° (Rear/Side)
Vertical Coverage Angle (-6dB)	50° / 30°(Rear/Side)
Configurable Coverage Patterns	SIDE/REAR
Nominal Impedance	8Ω
Sensitivity	102dB 1W/1m
Crossover Frequency	2,200Hz
Low Frequency Transducer	265H-1
High Frequency Transducer	1 x HF 2408H & 1 x 2414H
265H-1 Dimensions	Nominal Diameter 15" (38.1 cm)
2408 Dimensions	Nominal Diameter 1.5" (3.8 cm)
2424 Dimensions	Nominal Diameter 1" (2.5 cm)
Downward Firing Angle	10° for enclosure face
Enclosure Material	Plywood
Grille Color	Black
Input Connectors	Barrier Strip
Dimensions (H x W x D)	30.3" x 25.5" x 16.5" (769.6mm x 647.7mm x 419.1mm)
Net Weight (each)	64 lbs (29.03 kg)
