View larger image of Electro-Voice EVOLVE 90 — official front three-quarter view
17 attributes
| Attribute | Value |
|---|---|
| Brand | Electro-Voice |
| Series | EVOLVE |
| Model | EVOLVE 90 |
| Material Number | Z.01X.001.797 |
| Max SPL | 134 dB |
| Frequency Response | 35 Hz – 18,000 Hz |
| Frequency Range (-10 dB) | 28 Hz – 20,000 Hz |
| Coverage Angle | 120 × 25 |
| Total Output Power* | 2000 W |
| Phantom Power | Yes |
| Connectivity | powerCON power input Dual XLR/TRS combo jack mic / line inputs with switchable 48V phantom power Stereo XLR/TRS combo jack line input Stereo RCA line input XLR AES/EBU input XLR AES/EBU thru XLR Mix out XLR Sub out RJ45 QuickSmart Link connector Bluetooth Stereo input with TWS |
| Color | Black or white |
| Enclosure | Plywood with polyurea coating (subwoofer) Composite (column) Aluminum (pole) |
| Grille | Steel with black or white powder coat |
| Net weight | 44.5 kg (98.1 lb) |
| Shipping Weight | 94.8 lb (subwoofer) 25.1 lb (column and pole) |
| Series / Family | EVOLVE |
