Val Audio WCX8T Landscape Speakers

The VAL audio WCX8T is a high-performance 8″ two-way coaxial all-weather speaker, purposefully engineered for resilience and superior sound quality in demanding outdoor environment

Brand: Val AudioModel: WCX8T

The VAL audio WCX8T is a high-performance 8″ two-way coaxial all-weather speaker, purposefully engineered for resilience and superior sound quality in demanding outdoor environments. Its cabinet, precision-moulded from a specialized polymer compound, offers exceptional resistance to UV degradation, dust, and wind, ensuring long-term durability. The speaker features specially designed dustproof and waterproof covers for both input and output terminals, while a five-layer protective grille provides enhanced defence against water and dust ingress, fully meeting IP56 standards. All exposed metal components are crafted from premium stainless steel or aluminium, ensuring corrosion resistance, while the mounting bracket, made from low-carbon steel, is coated to withstand harsh weather conditions. At the heart of the WCX8T is a powerful 8″ ferrite mid-bass driver, paired with a coaxially mounted 1″ exit, 1.4″ (34mm) voice coil high-frequency driver, ensuring precise audio performance across the spectrum. For versatility, the WCX8T includes an integrated transformer with multiple power tap settings, allowing for easy adjustment between low-impedance (Low-Z) and high-impedance (High-Z) configurations via a rear panel rotary switch, making it suitable for a wide range of audio installations.

Features

8” two-way coaxial loudspeaker designed for weather-resistant performance Robust injection-moulded polymer cabinet for reliable operation in all-weather condition Coaxial point-source design with horn-loaded configuration for delivering high sound pressure levels (SPL) Powder-coated aluminium grille with five-layer protection, ensuring superior water ingress prevention Engineered to meet stringent IP56 weatherproofing standards for outdoor durability UV-resistant housing material for enhanced protection against prolonged sun exposure Corrosion-resistant components, including brass-embedded nuts, waterproof silicone covers, and stainless-steel screws Sealed, dustproof, and waterproof back panel covers and connectors for maximum environmental protection Supplied with a versatile U-bracket for secure and flexible mounting options

Attribute

Value

Model

WCX8T

Components

1×8” LF, 1×1” exit coaxial HF

Power Handling

200W RMS / 400W Program / 800W Peak

Impedance

8 ohm / 100V LMT in-built

Max SPL

124.5 dB

Nominal Impedance

8 ohms

Frequency Response (-10dB)

75Hz – 20KHz

Average Sensitivity

96dB (1W/1M)

Maximum SPL

118.5dB continuous / 121.5dB Program / 124.5dB peak

Low Frequency driver

1 x 8’’ (2’’ voice coil) ferrite woofer

High Frequency driver

1 x 1’’ (1.4’’ voice coil) driver coaxially mounted

Crossover Frequency

2.5 kHz passive

Dispersion (-6dB)

90° x 90°

LMT

Yes, 37.5W/75W/150W/8 ohm tapping

Input Connectors

Covered barrier strip terminals

Size (WxHxD)

300mm x 302mm x 348mm

Net Weight

11 Kg

Gross Weight

13 Kg
