Features

200 mm (8-inch) long-throw driver with polypropylene cone, long excursion TPV surround, and large-diameter 50 mm (2-inch) voice coil on glass fiber former

150W Pink Noise Power Handling (300W program) in direct 8Ω setting, plus built-in 80W subwoofer-band 70V/100V multi-tap transformer

Tough polyethylene enclosure resists abuse from lawn care equipment and the elements

IP56-rated to withstand the elements, with a tough polyethylene enclosure and a fully-sealed center wiring chamber

Frequency range: 40 Hz–150 Hz

Attribute

Value

Model

Control 89MS

Frequency Range (-10dB)

40 Hz – 150 Hz

Frequency Response (+/-3 dB)

53 Hz – 110 Hz

Power Rating

300 W: Continuous Program (2 hrs) 150 W: (600 W Peak), Continuous Pink Noise (2 hrs) 100 W: (400 W Peak), Continuous Pink Noise (100 hrs)

Sensitivity

87 dB (ave. 60 Hz – 105 Hz)

Maximum SPL

115 dB peak (109 dB continuous, 2 hr) @ 1m

Coverage Pattern

Omnidirectional

Directivity Factor (Q)

2.0 (with half-space, 2π, on-ground loading)

Directivity Index (DI)

3.0

Nominal Impedance

8 Ω (at 8Ω tap)

Transformer Taps

70V: 80 W, 40 W, 20 W, 10 W 100V: 80 W, 40 W, 20 W

Drivers

200 mm (8-inch) driver, polypropylene injection cone, long-excursion corrosionresistant TPV (thermoplastic vulcanizate) surround, and 50 mm (2-inch) voice coil on 80% glass fiber + polyamide coil former

Terminals

Bare wire with dielectric-gel-filled wire nuts (internal to top speaker section)

Enclosure Material

LDPE Polyethylene plastic, 6 mm minimum wall thickness, UL94V-HB rated,color throughout

Color

Hunter Green RAL 6018

Dimensions

524 x 355 x 355 mm (20.7 x 14.0 x 14.0 inches)

Included Accessories

(2) wire nuts, (2) gland nuts, (1) security screwdriver
