View larger image of TOA CS-154 — official product photo
13 attributes
| Attribute | Value |
|---|---|
| Model | CS-154 |
| Rated Input | 15 W |
| Rated Impedance | 100 V line: 670 Ω (15 W), 1 kΩ (10 W), 2 kΩ (5 W) 70 V line: 330 Ω (15 W), 670 Ω (7.5 W), 1 kΩ (5 W), 2 kΩ (2.5 W) |
| Sensitivity | 97 dB (1 W, 1 m) |
| Frequency Response | 150 - 15 kHz |
| Horizontal Directivity | Constant directivity horn 90° (±45° horizontal from front axis) 93 dB or more (1 W, 1 m), 3 kHz at ±45° |
| Speaker Component | 12 cm cone-type |
| Speaker Cable | 2-core cabtyre cord with diameter of 6 mm |
| Dust/Water Protection | IP65 |
| Operating Temperature | -20 °C to +55 °C |
| Finish | Horn, cover: ABS resin, off-white, paint Bracket: Stainless steel Net: Aluminum, gray, paint Screw: Stainless steel |
| Dimensions | 366 (W) x 230 (H) x 272 (D) mm |
| Weight | 2.8 kg |
