| Model | VRX932LAP |
|---|
| Power Rating | 1750 Watts Peak875 Watts Continuous |
|---|
| Frequency Range (-10dB) | 57 Hz - 20 kHz |
|---|
| Dimensions (H x W x D) | 349 mm x 597 mm x 444 mm(13.75 in x 23.5 in x 17.5 in) |
|---|
| Frequency Response | 75 Hz - 20 kHz (+/-3db) |
|---|
| Maximum SPL (1m) | 136 dB SPL |
|---|
| Coverage Pattern | 100 x 15 nominal |
|---|
| DPC-2 Output as (Continuous IED shaped pink noise into rated load impedance) | LF: 750 Watts, HF: 125 Watts |
|---|
| DPC-2 Output Section | LF: Dual-Bridged Technology, Class D |
|---|
| Inputs | XLR with loop through |
|---|
| LF Driver | 1 x JBL 2262FF 305 mm (12 in) neodymium magnet |
|---|
| HF Driver | 3 x JBL 2408J, 38 mm (1.5 in) |
|---|
| User Controls | Input Attenuator (0-16 dB) |
|---|
| Signal Processings | DSP based, resident in Input Module |
|---|
| AC Power Operating Range | 90-132 VAC or 216-264 VAC, 50/60 Hz |
|---|
| AC Input Connector | Neutrik PowerCon (NAC 3MPA) |
|---|
| AC Loop Through Connector | Neutrik PowerCon (NAC 3MPB) |
|---|
| AC Current Requirements | 6A per system at 120V, 3A per system at 240V |
|---|
| Enclosure | 25/15 mm, 11-ply birch plywood |
|---|
| Suspension / Mounting | Optional VRX-AF line array frame kit, 10mm forged eyebolts or internal dual angle 36mm pole mount cup for pole or tripod mounting |
|---|
