Features

Three-way ScreenArray design for optimal performance for solid screen cinema.

3733 is available only in bi-amp configuration

Design utilizes Dual Dissimilar Arraying technology to improve high frequency coverage and to shape the pattern for raked seating room design

The 2415-XP is JBL's next generation high-frequency compression driver

Advance waveguide design for improved frequency response and higher output with lower distortion

Used in conjunction with CRF2 reflector horns, which are used to reflect high frequency content off a solid screen

CRF2 includes the same HF driver as 3733 to maintain tonal quality

Attribute

Value

Model

3733

Frequency Response (±3 dB)

40Hz - 19kHz

Frequency Range (-10dB)

30Hz - 20kHz

System Input Power Rating

LF 800 watts, M/HF 300 watts

Horizontal Coverage Angle (-6dB)

100 degrees

Vertical Coverage Angle (-6dB)

Asymetrical with Dual Dissimilar Arraying

Net Weight

71.8 kg (158 lb)

Shipping Weight

86.7 kg (191 lb) Dimension (H x W x D) 1000 mm x 1648 mm

Dimensions (H x W x D)

1000 mm x 1648 mm x 450 mm (39.37 in x 64.88 in x 17.75 in)

Sensitivity

104dB @ 2.83V

Nominal Impedance

12Ω

Power Handling (2Hr AES Rating)

800W

Power Handling (100Hr AES Rating)

150 W

Net Weight (each)

158 lbs (71.8 kg)
