Features

Deep, commanding low end — up to 134 dB SPL from a 1,300 W Class-D amplifier.

Direct the bass — Cardioid Control Technology cuts up to 35 dB on stage with multiple subs.

Set it fast — QuickSmartDSP presets, system-match crossovers, and limiting on board.

EV-engineered sound — an 18-inch EVS-18C subwoofer driver for maximum output.

Runs cool under load — intelligent thermal management with a variable-speed fan.

Attribute

Value

Brand

Electro-Voice

Series

EKX

Model

EKX-18SP

Material Number

Z.01X.002.549

Max SPL

134 dB

Frequency Response

40 Hz - 150 Hz¹

Frequency Range (-10 dB)

35 Hz - 180 Hz¹

LF transducer size (in)

EVS-18C 457 mm (18 in)

Woofer Size

EVS-18C 457 mm (18 in)

Total Output Power*

1300 W

Power consumption (W)

1.8 A³

Connectivity

(2) XLR/TRS combo jacks and (2) XLR link outputs

Enclosure

15 mm plywood with EVCoat

Grille

18 AWG steel with powdercoat

Net weight

32.8 kg (72.4 lb)

Shipping Weight

41.2 kg (90.9 lb)

Dimensions (H x W x D) (mm)

520 mm x 606 mm x 612 mm

Series / Family

EKX
