Bose DML88P Pendant Speakers

DesignMax Luna makes it easy to get great sound in open-ceiling spaces. The proprietary Ring Array configuration combines eight 2-inch mid-high drivers with an integrated 8-inch woofer, delivering clear, balanced sound down to 40 Hz.

Brand: Bose ProfessionalModel: DML88P

DesignMax Luna makes it easy to get great sound in open-ceiling spaces. The proprietary Ring Array configuration combines eight 2-inch mid-high drivers with an integrated 8-inch woofer, delivering clear, balanced sound down to 40 Hz. With 111 dB max SPL and consistent 140° coverage, Luna reduces the number of speakers needed while preserving clarity, aesthetics, and design flexibility. Single- or two-point suspension allows for fast installs and perfectly balanced hangs — even in challenging ceiling conditions — while concealed wiring keeps everything looking clean. Luna marks a giant leap forward in pendant loudspeakers, raising the bar for what’s sonically possible in retail stores, restaurants, fitness studios, and other design-conscious spaces. The DesignMax Luna pendant loudspeaker offers full-range performance from a sleek, modern design

Request a quote WhatsApp

Features

Proprietary Ring Array configuration delivers precise, balanced sound with no hot spots or dead zones
Integrated 8” woofer extends down to 40 Hz—no subs needed
Wide-throw 140° coverage reduces speaker count and installation costs
Flexible mounting lets you use a single cable—or two-point suspension—for fast installs and perfectly balanced hangs
Streamlined design with concealed wiring and premium finish options
Factory-optimized loudspeaker presets when combined with Bose Professional amplifiers and processors
Compatible accessories include DesignMax Pendant Threaded Rod Adapter and Conduit Adapter

Specifications

25 attributes

Attribute	Value
Brand	Bose Professional
Series	DesignMax
Model	DML88P
Safety Agency Ratings	UL Listed, UL 1480A, NFPA 70 & NFPA 90A, CE-compliant
Colors	Black (similar to RAL 9005), white (similar to RAL 9003), paintable
Enclosure Material	Engineered plastics
Environmental	Indoors only; UL Listed, UL 1480A, NFPA 70 & NFPA 90A, CE-compliant
Grille	Perforated steel, powder-coated finish, paintable
Logo	Rotatable, removable
Suspension/Mounting	(1) 3-hole suspension cable attachment point
Product Dimensions (H×W×D)	308 mm × 492 mm (12.1 in × 19.4 in), loudspeaker diameter x depth
Net Weight	10.0 kg (22.0 lb)
Frequency Range (-10 dB)	40 Hz – 20,000 Hz
Coverage, Horizontal	140° conical
Calculated Maximum SPL @ 1 m	107 dB
Nominal Impedance	8 Ω (transformer bypass)
Power Handling, long-term continuous	140 W
Power Handling, Peak	560 W
Recommended Signal Processing	Not required, Bose Professional EQ voicing and SmartBass processing available
Sensitivity (SPL/1 W at 1 m)	85 dB
Transformer Taps, 100V
