| Brand | Bose Professional |
|---|
| Series | DesignMax |
|---|
| Model | DM10S-SUB |
|---|
| Safety Agency Ratings | UL-1480A, S5591/ UL Listed, NFPA70, CE compliant |
|---|
| Colors | Black (RAL 9005), white (similar to RAL 9003), paintable |
|---|
| Enclosure Material | High-density wood composite with solid color laminate, UV fade-resistant |
|---|
| Environmental | Indoor only |
|---|
| Grille | Perforated steel, powder-coated finish, paintable, tamper-resistant design |
|---|
| Logo | Rotatable, removable |
|---|
| Suspension/Mounting | QuickHold mounting system with included U-Bracket, (1) M8 safety cable attachment insert |
|---|
| Operating Temperature Range | 0 °C to 50 °C (32 °F to 122 °F) |
|---|
| Product Dimensions (H×W×D) | 19.8 in × 12.5 in × 12.7 in (502 mm × 316 mm × 323 mm), loudspeaker / 19.8 in × 12.5 in × 13.6 in (502 mm × 316 mm × 346 mm), loudspeaker with bracket |
|---|
| Net Weight | 35.5 lb (16.1 kg), loudspeaker with grille & bracket |
|---|
| Shipping Weight | 41.5 lb (18.8 kg) |
|---|
| Frequency Range (-10 dB) | 35 Hz – 125 Hz |
|---|
| Coverage, Horizontal | Omnidirectional below 200 Hz |
|---|
| Calculated Maximum SPL @ 1 m | 115 dB |
|---|
| Nominal Impedance | 8 Ω (transformer bypass) |
|---|
| Power Handling, long-term continuous | 300 W |
|---|
| Power Handling, Peak |
|---|
