Val Audio x118P Powered Subwoofers

The VAL Audio X118P is a high-output, self-powered 18” subwoofer engineered for professional touring, rental, and fixed installation environments requiring powerful, extended, and

Brand: Val AudioModel: x118P

The VAL Audio X118P is a high-output, self-powered 18” subwoofer engineered for professional touring, rental, and fixed installation environments requiring powerful, extended, and controlled low-frequency reinforcement. At the heart of the X118P is the 3000W Peak / 1500W RMS integrated high-efficiency Class D amplifier module optimized for 4-ohm operation. This ensures maximum energy transfer, improved damping control, and enhanced low-frequency punch. Built around VAL’s proprietary 18” high-excursion die-cast aluminium chassis driver, the X118P utilizes a precision-tuned bass reflex direct-radiating design to deliver deep and authoritative bass extension down to 34Hz with peak output levels reaching 134dB SPL. The enclosure is heavily braced to minimize vibrations and constructed from high-grade MDF with a touring-grade textured waterborne black finish for superior durability. A reinforced kick-proof steel grille with internal acoustic foam ensures driver protection without compromising acoustic transparency. Designed for maximum deployment flexibility, the X118P supports ground stacking, pole-mounted top systems, and flown configurations via integrated M10 rigging inserts.

Attribute

Value

Model

x118P

Components

1×18” LF

System Type

1×18” Bass Reflex / Direct Radiating Active Subwoofer System

Frequency Response (-3dB)

34Hz – 100Hz (DSP controlled HPF & LPF)

Maximum SPL

134dB Peak

Power Amplifier

High Efficiency Class D, 3000W Peak / 1500W RMS

Directivity

Omnidirectional

Integrated DSP

Master level control, 4 fixed DSP (Live/DJ/Monitor/Speech) modes, Limiter, Xover, EQ

Low Frequency Driver

1 x 18” (4” VC) high excursion, Die-cast aluminum chassis

Input Sensitivity

Line: 0.775V / 0 dBu

Input Impedance

10 kΩ balanced

Maximum Input Level

2.7V / 10.8dBu @ 32dB gain

Power Supply

115V / 230V, 50Hz – 60Hz, Input power

Connectors

Balanced XLR Female, Link balanced XLR Male, PowerCon In / link

Cooling

Smart thermal management via high speed fan

Power Consumption

885W

Enclosure

Heavily braced medium density fibreboard with durable scratch-resistant textured black finish

Grille

Kick-proof steel grille with internal acoustic foam and VAL logo

Rigging

12 x M10 inserts

Pole Mount

Integrated top-hat adapter

Dimensions (H x W x D)

537 x 630 x 605 mm
