| Model | TS-D1000-MU |
|---|
| Power Source | 100 - 240 V AC, 50/60 Hz (use of the supplied AC adapter) |
|---|
| Power Consumption | 60 W or less |
|---|
| Frequency Response | 100 Hz - 13 kHz |
|---|
| Distortion | 0.5 % or less |
|---|
| Signal to Noise Ratio | 80 dB or more (A-weighted) |
|---|
| Audio Transmission System | Time division multiplexing (TDM), 10 channels 16-bit PCM, 32 kHz sampling frequency |
|---|
| MIC Input | -54 dB (*2), 600 Ω, unbalance, Ø6.3 mm phone jack (2P) |
|---|
| Output | LINE: -10 dB (*2), 10 kΩ, unbalance, Ø6.3 mm phone jack (2P) REC: -10 dB (*2), 10 kΩ, unbalance, RCA pin jack, monaural HEADPHONES: Ø3.5 mm mini jack, monaural |
|---|
| Equalizer Input/Output Terminal | -10 dB (*2), 10 kΩ, unbalance, RCA pin jack |
|---|
| Video Conference System Input/Output Terminal | -10 dB (*2), 10 kΩ, unbalance, RCA pin jack |
|---|
| LED Indicator | Power indicator, Conference mode indicator, Number of open microphones indicators, Microphone auto off indicator, Monitor speaker of conference units volume indicators, Connection test indicator, External control indicator, Setting lock indicator, Recording status indicator, USB Access status indicator, USB memory status indicator, Internal memory status indicator, Remaining USB memory capacity warning indicator, Remaining internal memory capacity warning indicator, LINK/ACT indicator, 10BASE-T/100BASE-TX indicator |
|---|
| Number of Connectable Conference Units | 32 units |
|---|
| Number of Connectable Sub Control Units | 5 units |
|---|
| Maximum Cable Length | 50 m (164.04 ft) (between Master control unit and terminal Chairman/Delegate unit at end of daisy chain) (*3) 1 m (3.28 ft) (between Master control unit and Sub control units) (Use the cable supplied with the Sub control unit.) |
|---|
