Features

Versatile 3.5-inch full-range surface-mount speaker system

Perfect for music and announcements

Sleek design for seamless integration with walls and ceilings

Safe and easy installations with included mounting bracket

Temporary docking feature allows effortless wiring and positioning

Flexible angle adjustment for both wall and ceiling mounts

Ideal for permanent installs or portable setups

Attribute

Value

Model

F-03BT

Enclosure

Bass-reflex type

Rated Input

15 W (100 V line, 70 V line)

Power Handling

Rated noise power: 30 W (8 Ω) Continuous program: 60 W (8 Ω)

Rated Impedance

8 Ω 100 V line: 670 Ω (15 W), 2 kΩ (5 W), 3.3 kΩ (3 W), 10 kΩ (1 W) 70 V line: 330 Ω (15 W), 670 Ω (7.5 W), 2 kΩ (2.5 W), 3.3 kΩ (1.5 W), 10 kΩ (0.5 W)

Sensitivity

87 dB (1 W, 1 m) at installation in 1/2 free sound field

Frequency Response

85 Hz - 20 kHz, –10 dB at installation in 1/2 free sound field

Directivity Angle

Horizontal: 100°, Vertical: 100°

Speaker Component

9 cm (3.5") Full-range, PP cone-type

Input Terminal

Push-in Terminal

Installation Environment

Indoor installation

Operating Temperature

-10 °C to +50 °C (14 °F to 122 °F)

Finish

Enclosure: HIPS, black (RAL 9011 equivalent), paint Grille: Aluminum, black (RAL 9011 equivalent), paint Speaker bracket: Die-cast aluminum, black (RAL 9011 equivalent), paint Base bracket: Steel plate, t4, black (RAL 9011 equivalent), paint Base bracket cover: HIPS, black (RAL 9011 equivalent)

Dimensions

130 (W) x 221 (H) x 132 (D) mm (5.12" x 8.7" x 5.2")

Weight

1.7 kg (3.75 lb)

Included Accessories

Speaker bracket x 1, Base bracket x 1, Base bracket cover x 1, Bracket fixing screw x 1 set

Optional Accessories

Adapter plate: HY-F03B Speaker stand: ST-34B Note: K&M 19780 or K&M 19610 is required.
