Bose DM8SE Surface Mount Speakers

With coaxial two-way drivers, the 150-watt Bose Professional DesignMax DM8SE loudspeaker delivers powerful SPL suitable for foreground music — along with premium aesthetics that complement any commercial sound installation. The DM8SE features a two-way, 8-inch woofer and a center-firing coaxial 1-inch compression driver, delivering a 52 Hz – 20 kHz frequency range. The DM8SE is surface-mounted and locks onto a hidden QuickHold U-bracket for fast, secure installation.

Features

Combine DesignMax models to complete any design, big or small — 12 loudspeakers to mix and match, from 2-inch, low-profile models to 8-inch, high-SPL compression-driver loudspeakers and outdoor-rated options

Deliver rich lows and clear, intelligible highs with coaxial two-way drivers — no DSP or EQ required. For even better sound, use select Bose Professional DSPs and amplifiers to enable Bose Professional loudspeaker EQ and SmartBass processing, which expands performance and response at any listening level

Blend with any room design with elegant form factors, minimum-bezel grilles available in black or white, and removable logos

Reduce installation time with the patented QuickHold mounting system, which also reduces strain, hassle, and the chance of product damage

Install easily with industry-standard accessories — all models include Euroblock connectors; in-ceiling models include plenum-rated backcans, tile bridges, and front-access audio wiring that makes installation and troubleshooting easier

Deliver high SPL for clear foreground music

Install DM8SE outside — IP55 rating rating with standard aluminum grille for outdoor use

Attribute

Value

Brand

Bose Professional

Series

DesignMax

Model

DM8SE

Safety Agency Ratings

UL 1480A, NFPA 70, CE-compliant

Colors

Black (RAL 9005), white (RAL 9003), paintable

Enclosure Material

Engineered plastics, highly UV fade-resistant

Environmental

Outdoor per IEC 529 IP55 (suitable for use outdoors in wet locations), includes aluminum grille to prevent red corrosion and weather resistant input cover

Grille

Perforated aluminum, powder-coated finish, tamper-resistant design, paintable

Ingress Protection

IP55

Logo

Rotatable, removable

Operating Temperature Range

-25 °C to 70 °C (-13 °F to 158 °F)

Product Dimensions (H×W×D)

15.6 in × 9.8 in × 10.0 in (395 mm × 249 mm × 255 mm), loudspeaker / 15.6 in × 9.8 in × 10.7 in (395 mm × 249 mm × 272 mm), loudspeaker with bracket

Net Weight

22.8 lb (10.3 kg), loudspeaker with grille
