View larger image of A&T PTC20N V4 — official product photo
29 attributes
| Attribute | Value |
|---|---|
| Brand | A&T |
| Series | Professional Cameras |
| Model | PTC20N V4 |
| HDMI | / IP / 4 |
| USB | / 3G-SDI OUTPUT |
| Image Sensor | 1/2.8" CMOS, 2.14MP |
| Focal | Length f=4.7 - 94.0mm |
| Iris | F1.6 - F3.5 |
| Optical Zoom | 20X |
| Digital Zoom | 12X |
| FOV | 60 |
| Exposure | Control Auto, Manual, Shutter Priority, Iris Priority |
| White Balance | Auto, Manual, Indoor, Outdoor |
| Wide Dynamic | Yes |
| BLC | Yes |
| Pan | Angle/ Speed -170 ~ +170, 0.1 ~ 120/S |
| Tilt | Angle/ Speed -30 ~ +90, 0.1 ~ 80/S |
| Image Flip | Yes |
| Audio | Compression AAC |
| Protocols | ONVIF, ONVIF Prole S, RTSP, RTMP, HTTP, TCP, UDP |
| Network | Interface 10/100/1000M RJ45 |
| Control Interface | 1RS-485, 1RS-232 IN, 1RS-232 OUT |
| NDI | Supported |
| Power | DC12V |
| Operating Temperature | 0C ~ +40C |
| Storage Temperature | -20C ~ +60C |
| Dimensions | LWH 243mm145mm163mm |
| Weight | 1.2KG |
|---|
| Total Zoom | 20x |
|---|
